CY7C1305TV25-167BZC

CY7C1305TV25-167BZC, Synchronous Pipelined SRAM, 2.9V, 20 mA, 167 MHz, BGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $19.18~19.67 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	19.67 / Piece
110 ~ 500 :	19.34 / Piece
510 ~ 2000 :	19.18 / Piece

PartNumber:: CY7C1305TV25-167BZC

Brand:: Cypress Semiconductor - Cypress | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Nicole's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-28

From Other Seller

Part Number:CY7C1305TV25-167BZC
US $19.18 - 19.67
Quantity:

piece

Product Summary

The CY7C1305TV25-167BZC is a 1.8V Synchronous Pipelined SRAM equipped with QDR architecture. QDR architecture consists of two separate ports to access the memory array. The CY7C1305TV25-167BZC has dedicated Data Outputs to support Read operations and the Write Port has dedicated Data Inputs to support Write operations.

Parametrics

CY7C1305TV25-167BZC absolute maximum ratings: (1)Storage Temperature : –65°C to +150°C; (2)Ambient Temperature with Power Applied : –55°C to +125°C; (3)Supply Voltage on VDD Relative to GND : –0.5V to +2.9V; (4)DC Applied to Outputs in High-Z State : –0.5V to VDDQ + 0.5V; (5)DC Input Voltage[11]: –0.5V to VDDQ + 0.5V; (6)Current into Outputs (LOW): 20 mA; (7)Static Discharge Voltage : > 2001V (per MIL-STD-883, Method 3015); (8)Latch-Up Current : > 200 mA.

Features

CY7C1305TV25-167BZC features: (1)4-Word Burst for reducing the address bus frequency; (2)Double Data Rate (DDR)interfaces on both Read & Write Ports (data transferred at 333 MHz)@167 MHz; (3)Two input clocks (K and K)for precise DDR timing: SRAM uses rising edges only; (4)Two output clocks (C and C)accounts for clock skew and flight time mismatching; (5)Single multiplexed address input bus latches address inputs for both Read and Write ports; (6)Separate Port Selects for depth expansion; (7)Synchronous internally self-timed writes; (8)1.8V core power supply with HSTL Inputs and Outputs; (9)13 x 15 x 1.4 mm 1.0-mm pitch fBGA package, 165 ball (11x15 matrix); (10)Variable drive HSTL output buffers; (11)Expanded HSTL output voltage (1.4V–1.9V); (12)JTAG Interface.
