Product Summary

The BCM5912A2KQM is a 7.2-MBPS HEDGE 65-nm multimedia baseband processor. It features WCDMA, 7.2-Mbps HSDPA and EDGE Class 12 capability to provide full support for 2G and 3G voice and high-speed data. Full inter-RAT operation is supported for seamless global roaming on EDGE/GPRS/GSM and HSDPA/WCDMA networks worldwide. The applications of the BCM5912A2KQM include Mobile handsets and smartphones.

Parametrics

BCM5912A2KQM absolute maximum ratings: (1)Place of Origin: Kansas, United States; (2)Brand Name: BROADCOM; (3)Model Number: BCM5912A2KQM; (4)Type: Timer; (5)Application: Computer ; (6)Supply Voltage: 2.7V to 5.5V; (7)Dissipation Power: subject as standard goods; (8)Operating Temperature: -40℃ to 85℃; (9)Description: QFP; (10)Condition: new original and stock.

Features

BCM5912A2KQM features: (1)Single-chip, single-die, 7.2-Mbps HSDPA/EDGE baseband processor; (2)Complete system-on-a-chip, high-end multimedia with advanced audio, high-speed 480-Mbps USB 2.0 OTG, full mixed-signal support for speakers, Hi-Fi stereo audio amplifiers and USB transceivers, full security and DRM, and high performance 312-MHz ARM1 applications processor; (3)Advanced release 6 compliant equalizer and 208-Mhz ARM9 for communications; (4)Utilizes the lowest cost, lowest power 65-nm digital CMOS process; (5)Compact 13 mm x 13 mm 517-pin FBGA package for low-cost PCB design.

Diagrams

BCM5912A2KQM pin connection
