Product Summary
The PT6959 is an LED Controller driven on a 1/4 to 1/7 duty factor. Fourteen to eleven segment output lines, 4 to 7 grid output lines, one display memory, control circuit are all incorporated into a single chip to build a highly reliable peripheral device for a single chip microcomputer. Serial data is fed to the PT6959 via a three-line serial interface. Housed in a 28-pin SO Package, the PT6959s pin assignments and application circuit are optimized for easy PCB Layout and cost saving advantages.
Features
PT6959 features: (1)CMOS Technology; (2)Low Power Consumption; (3)8-Step Dimming Circuitry; (4)Serial Interface for Clock, Data Input, Strobe Pins; (5)Available in 28-pin, SO Package.
