XC3S1200E-4FGG320C

XC3S1200E-4FGG320C, field-programmable gate array, 1.32V, 326 MHz, BGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $22.95~25.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 50 :	25.00 / Piece
51 ~ 100 :	23.78 / Piece
101 ~ 2000 :	22.95 / Piece

PartNumber:: XC3S1200E-4FGG320C

Brand:: Xilinx, Inc - Xilinx | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Nicole's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-14

From Other Seller

Part Number:XC3S1200E-4FGG320C
US $22.95 - 25.00
Quantity:

piece

Product Summary

The XC3S1200E-4FGG320C is a field-programmable gate array. The XC3S1200E-4FGG320C is specifically designed to meet the needs of high volume, cost-sensitive consumer electronic applications. The XC3S1200E-4FGG320C is ideally suited to a wide range of consumer electronics applications, including broadband access, home networking, display/projection and digital television equipment.

Parametrics

XC3S1200E-4FGG320C absolute maximum ratings: (1) Internal supply voltage VCCINT: -0.5V to 1.32V; (2) Auxiliary supply voltage VCCAUX: -0.5V t0 3.0V; (3) Output driver supply voltage: -0.5V to 3.75V; (4) Input reference voltage VREF: -0.5V, VCCO +0.5V; (5) Voltage applied to all Dedicated pins: -0.5V VCCAUX +0.5V; (6) Junction temperature TJ: VCCO≤3.0V, 125°C, VCCO＞3.0V, 105°C; (7) Soldering temperature TSOL: 220°C; (8) Storage temperature Tstg: -65°C to 150°C.

Features

XC3S1200E-4FGG320C features (1) Densities as high as 74,880 logic cells; (2) 326 MHz system clock rate; (3) Three power rails: for core (1.2V) , I/Os (1.2V to 3.3V) , and auxiliary purposes (2.5V) SelectIO signaling; (4) Seven differential signal standards including LVDS; (5) Termination by Digitally Controlled Impedance; (6) Signal swing ranging from 1.14V to 3.45V; (7) Double Data Rate (DDR) support; (8) Eight global clock lines and abundant routing.
