AT25DF641-MW

AT25DF641-MW, serial interface Flash memory device, 4.1V, 20 Years, QFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.10~2.45 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.45 / Piece
110 ~ 500 :	2.30 / Piece
510 ~ 2000 :	2.10 / Piece

PartNumber:: AT25DF641-MW

Brand:: ATMEL Corporation - Atmel | Pack: QFN | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Nicole's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-24

From Other Seller

Part Number:AT25DF641-MW
US $2.10 - 2.45
Quantity:

piece

Product Summary

The AT25DF641-MW is a serial interface Flash memory device designed for use in a wide variety of high-volume consumer based applications in which program code is shadowed from Flash memory into embedded or external RAM for execution. The flexible erase architecture of the AT25DF641-MW, with its erase granularity as small as 4-Kbytes, makes it ideal for data storage as well, eliminating the need for additional data storage EEPROM devices.

Parametrics

AT25DF641-MW absolute maximum ratings: (1)Temperature under Bias: -55 to +125℃; (2)Storage Temperature: -65 to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +4.1V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.5V.

Features

AT25DF641-MW features: (1)Single 2.7V - 3.6V Supply; (2)Serial Peripheral Interface (SPI) Compatible; (3)Very High Operating Frequencies; (4)Flexible, Optimized Erase Architecture for Code + Data Storage Applications; (5)Individual Sector Protection with Global Protect/Unprotect Feature; (6)Hardware Controlled Locking of Protected Sectors via WP Pin; (7)Sector Lockdown; (8)128-Byte Programmable OTP Security Register; (9)Flexible Programming; (10)Fast Program and Erase Times; (11)Program and Erase Suspend/Resume; (12)Automatic Checking and Reporting of Erase/Program Failures; (13)Software Controlled Reset; (14)JEDEC Standard Manufacturer and Device ID Read Methodology; (15)Low Power Dissipation; (16)Endurance: 100,000 Program/Erase Cycles; (17)Data Retention: 20 Years; (18)Complies with Full Industrial Temperature Range; (19)Industry Standard Green (Pb/Halide-free/RoHS Compliant) Package Options.
