Product Summary

The BAT54C is a surface mount schottky barrier diode.

Parametrics

BAT54C absolute maximum ratings: (1)Peak Repetitive Reverse Voltage: 30 V; (2)Working Peak Reverse Voltage: 30 V; (3)DC Blocking Voltage: 30 V; (4)Forward Continuous Current: 200 mA; (5)Repetitive Peak Forward Current: 300 mA; (6)Forward Surge Current @ t < 1.0s: 600 mA; (7)Power Dissipation: 200 mW; (8)Thermal Resistance, Junction to Ambient Air: 500 ℃/W; (9)Operating and Storage Temperature Range: -65 to +125 ℃.

Features

BAT54C features: (1)Low Turn-on Voltage; (2)Fast Switching; (3)PN Junction Guard Ring for Transient and ESD Protection; (4)Lead Free/RoHS Compliant; (5)Qualified to AEC-Q101 Standards for High Reliability.

Diagrams

BAT54C pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BAT54C
BAT54C

Fairchild Semiconductor

Schottky (Diodes & Rectifiers) 30V 200mA

Data Sheet

0-1: $0.12
1-25: $0.11
25-100: $0.07
100-250: $0.03
